Freedom SW Series Power Inverter/Charger
| 815-2012 |
| Watts | 2000 Continious |
| Volts | 120 AC |
| Frequency | 60 Hz |
| Charger Amps | 100 |
The Freedom SW 2000 inverter/charger features pure sine wave output and power factor corrected multi-stage charging to meet power needs of today’s sensitive and sophisticated electronics. It provides 2000 watts of continuous sine wave power to operate commonly used AC-powered electronics such as plasma television sets, microwaves, entertainment systems, computers, printers, power tools, mini refrigerator and much more.
Application
Designed for a variety of mobile applications such as commercial, emergency and recreational vehicles, marine vessels, construction and military equipment
Built-in transfer switch automatically transfers between inverter power and incoming AC power
Power factor corrected multi-stage charger for fast, efficient charging
Temperature compensated charging for all climate conditions
Wide operating temperature range: 32°F to 122°F (0°C to 50°C)
Ignition lockout prevents unnecessary battery drain when the alternator is not providing power*
Adjustable low-voltage disconnect
Conformal coated circuit boards for humid environments
On/off remote control panel with 25’ cable included (Part# 808-9002)
Easy to install and easy to use
Optional GFCI (part# 808-9003)
Meets CSA, UL458 (with marine supplement), ABYC and FCC Part 15, Class B requirements
*when used with On/Off Remote Switch
Protection Features
- Battery over-voltage and under-voltage protection
- Over-temperature shutdown
- Automatic overload protection
- Short-circuit protection
- Ground-fault protection on units with GFCI option
Master carton dimensions (H x W x L) 11.8 x 17.1 x 20.5” (30 x 43.5 x 52.2 cm)
Carton Weight 66 Pounds
Product Code: 262-8152012
