Rectifier
18-5708
Fits:1967-1996 50, 55, 60, 65, 70, 75, 85, 88, 90, 100, 110, 112, 115, 125, 135, 140, 150, 175, 185, 200, & 235 HP Engines
4-Wire Ring Terminal
Johnson/Evinrude: 580795, 581603,582307, 582399 and 583408
This rectifier has recently been changed by the manufacturer from 3 wire to 4 wire. The Black wire with the fork terminal is to be inserted under one of the mounting screws
Do Not Use Maintenance Free Battery. Over-Voltage Will Occur
 |
| Applications |
| Model/HP | Year |
| 50 HP (2 Cyl) | 1971, 1973-1975 |
| 50 HP (2 Cyl) Elect Start | 1972 |
| 55 HP (2 Cyl) | 1976-1977 |
| 60 HP (3 Cyl) | 1970-1971 |
| 60 HP (3 Cyl) EL/TL | 1986-1990 |
| 60 HP (3 Cyl) TTL | 1988-1990 |
| 60 HP (3 Cyl) SST | 1989-1990 |
| 60 HP (3 Cyl) EL/TL/TX | 1991 |
| 65 HP (3 Cyl) | 1972-1973, 1989 |
| 65 HP (3 Cyl) Comm | 1984-1990 |
| 65 HP (3 Cyl) Comm, Elec.Strt | 1991 |
| 70 HP (3 Cyl) | 1973-1985, 1988-1990 |
| 70 HP (3 Cyl) EL/TL | 1986-1987 |
| 70 HP (3 Cyl) EL/TL/TX | 1991 |
| 75 HP (3 Cyl) | 1975-1976, 1978-1985, 1988 |
| 75 HP (3 Cyl) EC | 1986-1987 |
| 85 HP (4 Cyl) | 1970-1983 |
| 88 HP (4 Cyl) | 1987-1988 |
| 88 HP (4 Cyl) W/O Trim | 1989-1991 |
| 88 HP (4 Cyl) TS W/20" Shaft | 1994-1995 |
| 88 HP (4 Cyl) MS | 1995-1996 |
| 88 HP (4 Cyl) TS W/20" Shaft | 1996 |
| 90 HP (4 Cyl) 6 Amp | 1984 |
| 90 HP (4 Cyl) W/O Trim | 1985-1987 |
| 90 HP (4 Cyl) | 1988 |
| 90 HP (4 Cyl) W/O Trim | 1989-1990 |
| 90 HP (4 Cyl) W/O Trim | 1994 |
| 90 HP (4 Cyl) 20" shaft | 1996-1997 |
| 100 HP (4 Cyl) Starflite | 1967-1968 |
| 100 HP (4 Cyl) | 1971-1972 |
| 100 HP (4 Cyl) W/O Trim | 1990 |
| 100 HP (4 Cyl) W/O Trim | 1994 |
| 100 HP (4 Cyl) Comm | 1987 |
| 100 HP (4 Cyl) Comm,W/O Trim | 1990 |
| 110 HP (4 Cyl) W/O Trim | 1986-1987 |
| 110 HP (4 Cyl) TLCDF, W/O Trim | 1986 |
| 112 HP (4 Cyl) 20" Shaft | 1994-1996 |
| 115 HP (4 Cyl) | 1969-1970 |
| 115 HP (4 Cyl) 6 Amp | 1973 |
| 115 HP (4 Cyl) 12 Amp | 1974-1976 |
| 115 HP (4 Cyl) | 1977-1983 |
| 115 HP (4 Cyl) 6 Amp | 1984 |
| 115 HP (4 Cyl) W/O Trim | 1985, 1990, 1994 |
| 115 HP (4 Cyl) 20" Shaft | 1997 |
| 125 HP (4 Cyl) | 1971-1972 |
| 135 HP (4 Cyl) | 1973-1976 |
| 140 HP (4 Cyl) | 1973-1983 |
| 140 HP (4 Cyl) 6 Amp | 1984 |
| 150 HP (6 Cyl) | 1978 |
| 175 HP (6 Cyl) | 1977-1978 |
| 200 HP (6 Cyl) | 1976-1978 |
| 235 HP (6 Cyl) | 1978 |
| 1.6 L (8 Cyl) | 1983 |
| 2.5 L (6 Cyl) | 1982 |
| 2.6 L (6 Cyl) | 1982 |
| 2.6 L (6 Cyl) 1AA/2BA/2BB, 10 Amp | 1983 |
| Options |
 | AR103 |
 | 153-3408 |
Product Code: 47-5708
